SecurityMetrics Internal Scan (Vision) installation instructions

Connect device to your network

In order to function properly, please be sure your device is physically connected to your network.

• Select a good location for the device, close to power and a network port, and away from unauthorized access or disruption.
• Connect an ethernet cable to Port 2 on the Vision device, and connect to your local network.
• Connect the power cable to the device and plug it in.

Configure your firewall to support your device (optional)

NOTE: This step is only needed if your firewall is configured to restrict outbound access.

• The following ports must be opened for outbound traffic between the sensor and SecurityMetrics:
• TCP: 80, 443, 3219, 8457, 8932, 9093, 62513
• UDP: 10490-10500
• Your firewall must allow the device to connect to SecurityMetrics IP addresses.  There are two methods to accomplish this and both are shown below, however, only one is necessary.

Preferred:  Enable the fully qualified domain name (FQDN) *.securitymetrics.com

Note: The above address & port configuration may need to be updated from time-to-time.

Alternate:  Enable the following IP addresses (and ranges):

• 204.238.82.53 TCP Ports 80, 443,3219, 8457, 8932, 9093,62513
• 204.238.82.50  TCP Port 443
• 204.238.82.52  TCP Port 443
• 76.8.204.12 TCP Port 443
• 162.211.152.0/24  UDP 10490 - 10500

Note: The above address & port configuration may need to be updated from time-to-time.

Verify everything is working properly

• Go to www.securitymetrics.com/login and sign in using the primary admin email and password.
• Select “Pulse” from the menu in the upper left corner.
• In the Dashboard screen, find your device in the list and verify that the Status & SM Link both say “Online"
